PT Humpuss Aromatik refinery as Condensate Processing Unit (CPU) and next step we have plan to expand to petrochemical area. PT Humpuss Aromatik Condensate Processing Unit location
PROCESS UNIT
Process Unit
- Precut column
- Condensate Splitter column
- Debutanizer column
- Kerosene Stripper
- Gas Oil Stripper
- 2 unit Fired Heater
UTILITIES & OFFSITES UNIT
Water Treatment System
- Raw Water unit, capacity 45 m3/jam
- Boiler Feed Water unit, capacity 36 m3/jam
- Potable Water unit, capacity : 5 m3/jam
Steam Generation System
- capacity : 34 ton/jam
Plant and Instrument Air System
- capacity : 389 nm3/jam
Instrumentation using DCS Honeywell TDC 3000
Waste Water Treatment System
- capacity 30 m3/jam
Fire and Safety System
Flare System
Power Generation System
- Gas Turbine, capacity : 9.5 MW
- Stand By Generator, capacity : 1 MW
Product and Slop Oil Tanks
- LPG Sphere 1 ea, capacity : 5,000 m3
- Light Naphtha tanks 3 ea, capacity : 20,000 m3
- Heavy Naphtha tanks 3 ea, capacity : 20,000 m3
- Kerosene tanks 2 ea, capacity : 20,000 m3
- Gas Oil tanks 1 ea, capacity : 8,000 m3
- Fuel Oil tanks 1 ea, capacity : 8,000 m3
- Slop Oil tank 1 ea, capacity : 8,000 m3
LPG Vaporizer and LPG Truck Loading
Buildings (Control room, Office, Warehouse, Laboratory and Maintenance shop)
DESIGN CAPACITY
Design Capacity
The Condensate Processing Unit (CPU) is designed to process 70,000 barrels per stream day (BPSD) or 464 cubic meters per hour (m3/hr) of Condensate from domestic and imported sources.
The design capacity is based on 100 % Arun Condensate or 100 % Northwest Shelf (NWS) Condensate.
ENVIRONMENTAL, HEALTH & SAFETY
Air Quality Considerations
- Lo-NOX burners
- Relief valves
- Internal floating
- Fixes cone roofs
Waste Treatment
- CPI/Waste water treatment unit
- Sanitary waste water treatment unit
Fire Protection System
- The fire water pumps & distribution systems
- Fire-resistant materials
- Fire extinguishing systems
